Slip rings and split rings greatly differ in terms of structure. A slip ring is a continuous and cylindrical piece, aligned concentrically with the device's shaft. The design allows free rotation and smoothened transmission of power and signals. The split ring, on the contrary, has a cut or split in its structure.. The slip ring and split ring might easily confuse someone who is not non-technical. They are different meanings, but often get mixed up. A slip ring is an electromechanical device that allows electrical signals and power to be transmitted from a stationary part to a rotating part, while a split ring is used to reverse the direction of the current in a DC motor.
